L-Acoustics 5XT Loudspeaker

Overview

5XT is an ultra-compact coaxial system designed for short throw sound reinforcement applications requiring minimum visual impact. 5XT features a 1’’ diaphragm compression driver coaxially loaded by a 5’’ low-mid frequency transducer mounted in a bass-reflex cabinet.

For Hire L-Acoustics

Specs

Max SPL:

121 dB

Bandwidth:

95 Hz – 20 KHz

Transducers:

LF: 1 x 5″, HF: 1 x 1″

Weight:

3.5 kg

Directivity:

H: 110°, V: 110°

Additional Information

Delivery Options Available

Serviced & Quality Approved

Flexible Rental Periods

The L-Acoustics 5XT is an ultra-compact, high-performance coaxial loudspeaker designed for discrete sound reinforcement in a wide range of applications. As the smallest member of the L-Acoustics X Series, the 5XT offers exceptional audio quality and flexibility, making it ideal for use in settings where space is limited but sound quality cannot be compromised.

Key Features:

Coaxial Transducer Design: The 5XT features a 2-way coaxial transducer configuration, with a 5-inch low-frequency driver and a 1-inch diaphragm compression driver. This design provides a single point source, ensuring excellent phase coherence and uniform frequency response across its coverage area.
Wide Coverage: The 5XT delivers a 110° conical directivity, providing broad and even coverage, making it suitable for applications that require consistent sound distribution over a wide area.
Compact and Lightweight: Weighing just 3.5 kg and with a compact form factor, the 5XT is easy to integrate into spaces where larger speakers would be impractical. Its small size makes it ideal for discreet installations where visual impact needs to be minimal.
High SPL and Clarity: Despite its small size, the 5XT is capable of delivering a maximum SPL of 121 dB, ensuring clear and powerful sound output suitable for both speech and music reinforcement in small to medium-sized venues.
Versatile Mounting Options: The 5XT is designed for flexible deployment, featuring an integrated 3/8”-16 thread insert for easy mounting on stands, trusses, or walls. Optional mounting accessories allow for a variety of installation configurations, whether used as a standalone speaker or as part of a larger system.
Rugged Construction: Built to endure the demands of professional use, the 5XT features a durable, weather-resistant enclosure with a robust polyurea coating, making it suitable for both indoor and outdoor applications.
Optimized for LA Series Amplifiers: The 5XT is designed to work seamlessly with L-Acoustics’ LA4X or LA8 amplified controllers, which offer preset configurations to optimize the speaker’s performance and ensure long-term reliability.

Applications:

The L-Acoustics 5XT is ideal for a variety of professional audio applications, including:

Corporate Events and Conferences: The 5XT’s compact size and high speech intelligibility make it perfect for corporate presentations, conferences, and other events where clear audio is essential.
Fill and Delay Speakers: In larger sound systems, the 5XT can be used as a fill or delay speaker, providing supplementary coverage in areas where the main PA system may not reach, such as under balconies or in side areas.
Houses of Worship: The 5XT’s discreet design and high-quality sound make it well-suited for use in worship spaces, where aesthetics and audio clarity are both important.
Hospitality and Retail: Its small size and unobtrusive design make the 5XT ideal for background music and announcements in restaurants, retail stores, and other hospitality environments.

Performance and Discretion:

The L-Acoustics 5XT is a powerful tool for sound professionals who need high-quality audio in a compact package. Whether used in standalone applications or as part of a larger system, the 5XT delivers precise, clear sound with minimal visual impact, making it an excellent choice for any setting where both sound quality and discretion are paramount.
